XT60 power connectors - High-current power connectors by AMASS

TME’s offer now includes new DC connectors by AMASS. They’re made according to the XT60H standard and offer excellent connection performance.

Therefore, they are widely applied in e.g. RC modelling, where they supply voltage from lithium polymer (LiPo) and lithium-ion (Li-ion) batteries to power drives.

They’re also keenly used by electric bike designers and manufacturers as high-current motor control connections.

*XT60H-F female connector

*XT60H-M male connector

Made of polyamide, the connector housings offer high thermal tolerance. They can operate in temperatures ranging from -20°C to 120°C.

The use of nylon also ensures mechanical durability.

The contacts are made of gold-plated brass, thanks to which they demonstrate resistance to corrosion and are able to handle currents up to 30A.

AMASS connectors have been available in TME's catalogue for several years and are very popular among our customers.

New products on our offer are female and male connectors: XT60H-F and XT60H-M.

Photo: TME

Specification

Type of connector power DC

Rated voltage 500V

Rated current 30A

No. of pins 2

Contact material brass

Body material polyamide

Operating temperature from -20°C to 120°C

Flammability rating UL94V-0

Electrical mounting soldered

Mechanical mounting cable

Spatial orientation straight

The original source of text: TME
